Product Description
1. Power: 2 motors with inverters speed control.
2. Printing : 1 color engravure printing .
3. Coating : automatic blade transfer coating ,make different coating thickness on same machine .
4. Drying: water tank inside, heating by electricity .
5. Energy saving temperature control: Two segmented automatic temperature controls.
6. 4 shafts rotary rewinding ,easy operation.
7. EPC for guiding right direction of film walking & flat rewinding edge of the tapes.
Main Technical Parameters:
| Item | GL-500c |
| Dimensions | 7.60m*1.3m*2.40m |
| Power | 3-phase,380v,50Hz,15kw |
| Printing | 1 color engravure printing |
| Max.coating width | 500mm |
| Max.coating speed | 25m/min |
| Max.loading diameter | 600mm |
| Max.rewinding diameter | 180mm |
| Drying | heating water by electricity |
